Description
Product details
■ Operating voltage:: DC12-36V■ Rated output power: 5W■ Frequency response: 20Hz～20KHz■ Noise voltage: ≤50MV■ Signal to noise ratio: ≥85db■ Sound levelabout 120DB■ Maximum working current: 1000mA■ Working environment temperature: - 40 ~ + 85 ℃ industrial standard■ Working environment humidity: 10% ~ 98%■ IP Rating: IP65■ Audio Format: Mp3■ Surrounding Flashing: 70-80 Min
![♦ Product Name DC TO DC CONVERTER 12-24V-132W]
♦ Model No.: HIS-12-24-132W
♦ Input Voltage: DC 12V
♦ Input Voltage Range: DC 9-23V
♦ Output Voltage: DC 24V
♦ Output Current: 5.5A
♦ Output Power: 132W
♦ Conversion Efficiency: >93%
♦ Cable Length: 13-14cm
♦ Ripple (Full load test)40mV
♦ No-load current: : 3.5mA
♦ Working Temperature: -40~80℃ ( If ambient temperature exceeds 40°C, lower power use, or to enhance heat dissipation)
♦ Waterproof Rating: IP67
♦ Protection: Over-current /Over-voltage/Over-heat/Short-circuit Waterproof, Anti-shock , Anti-dust protection
♦ Material: ABS Plastic](https://productimages.withfloats.com/tile/690d9ba0613a3dd4f6e38608.png)
