Forklift Anti collision Radar Detection Sensor System

Product Keywords:

*Single sensor operation

*Advanced microwave sensing technology

*Automatically activated when the driver shifts vehicle into reverse status

*The device is capable of visualizing the radar-zones on the display. As soon as an object enters the detection zone it will activate a transparent *colored visualization alert in the monitor to make the driver aware of the potential danger. (Green - Far, Yellow - Middle, Red - Close).

*Detect moving objects including any transportation vehicles, motorcycles, bicycles, pedestrians, etc.

*Work effectively in harsh environment and in poor visibility including darkness, smoke, fog and dust

*1 CH Camera input and 1 CH video out for AHD.

*Support 2CH radar sensor input

Accessories:

*Monitor - 01 Nos

*Camera - 1 Nos

*Sensor - 01 Nos

*Cable 1.5M 4-42 - 01 Nos

*Control Box- 01 Nos

*Cable 3M 10 - 01 Nos

*Buzzer - 01 Nos

*Cable 1M 370 - 01 Nos

*Cable 3M 59 - 02 Nos

*Operation Manual & Some installation accessories

*Dimensions : Sensor 70.5(W) x 39.5(H) x 22.5(D) mm / Control Box 152.6(W) x 89.2(H) x 53.8(D) mm

*Transmitter Type: FMCW

*Voltage: 10-30 VDC

*Weight: 85 Grams (sensor) 240 Grams (control box)

*Detecting Distance: 0.1 - 20m,equally divided in 5 detection zones

*Detection Zone Visualization : Green (furthest),Yellow(middle),Red (closest)

*Detection Tolerance: +/-10cm

*IP Protection: IP67 (sensor)/ Display & Camera

*Vibration Rating: 5.9 gm

*Power Supply: 10 to 32 VDC

*Operating Temperature: -20 to +70 deg C

*Storage Temperature: -30 to +80 deg C

*Model Number: HIS-FLWS-040
